| Function |
BTC/BCH/BSV SHA256 Air-cooling Miner |
| Specifications |
234T 3510W 15J/T |
| Specifications
| Product Glance |
|
| Model |
S21 Pro |
| Algorithm | Cryptocurrency |
SHA256 | BTC/BCH |
| Hashrate, TH/s |
234 |
| Power on wall @25°C, Watt |
3510 |
| Power efficiency on wall @25°C, J/TH |
15 |
| Detailed Characteristics |
|
| Power supply |
|
| Power supply AC input voltage, Volt(1-1) |
220~277 |
| Power supply AC input frequency range, Hz |
50~60 |
| Power supply AC input current, Amp(1-2) |
20(1-3) |
| Adapted AC output power requirement, W(2-3) |
4000 |
| Hardware Configuration |
|
| Network connection mode |
RJ45 Ethernet 10/100M |
| Miner size (length*width*height, w/o package),mm(2-1) |
450*219*293 |
| Miner size (length*width*height, with package),mm |
680*390*450 |
| Net weight, kg(2-2) |
20 |
| Gross weight, kg(2-2) |
22 |
| Noise@25℃(2-4)，dBA |
76 |
| Environment requirements |
|
| Operation temperature,°C |
-20~45 |
| Storage temperature,°C |
-20~70 |
| Operation humidity(non-condensing) , RH |
10%~90% |
| Operation altitude, m(3-1) |
≤2000 |
NOTE:
(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values, The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-2) Inlet air temperature.
(2-1) Caution: Wrong input voltage may probably cause server damaged.
(2-2) Single-phase AC input 20A.
(2-3) Max condition: Fan is under max RPM(rotation per minute).
(2-4) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
