| Product Glance |
Value |
| Model |
S19 XP Hyd. |
| Crypto algorithm/coins |
SHA256 | BTC/BCH/BSV |
| Typical hashrate, TH/s(1-1) |
257 |
| Power on wall @35°C(1-2), Watt(1-1) |
5346 |
| Power efficiency on wall @35°C(1-2), J/T(1-1) |
20.8 |
| Detailed Characteristics |
Value |
|
| Power supply |
|
|
| Phase |
3 |
|
| Input voltage, Volt(2-1) |
380~415 |
|
| Input frequency range, Hz |
50~60 |
|
| Input max current, Amp |
12 |
|
| Hardware Configuration |
|
|
| Network connection mode |
RJ45 Ethernet 10/100M |
|
| Server size (length*width*height, w/o package), mm |
410*170*209 |
|
| Server size (length*width*height, with package), mm |
570*316*430 |
|
| Net weight, kg |
12.8 |
|
| Gross weight, kg |
14.1 |
|
| Environment Requirements |
|
|
| Inlet coolant temperature, ℃ |
20~40 |
| Coolant flow, L/min |
8.0~10.0 |
| Coolant pressure, bar |
≤3.5 |
| Working coolant(2-2) |
Antifreeze/ Pure water/Deionized water |
| Coolant pH value |
Antifreeze: 7.0~9.0
Pure water: 6.5~7.5
Deionized wate: 8.5~9.5
|
| Diameter of coolant pipe connector, mm |
OD10 |
| Storage temperature, °C |
-20~70 |
| Operation humidity(non-condensing), RH |
10%~90% |
Notes:
(1-1) The hashrate value, power on wall, and power efficiency on wall are all typical values. The actual hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-2) Inlet water temperature.
(2-1) Caution: Wrong input voltage may cause server damaged.
(2-2) For detailed working coolant use and maintenance instructions, please refer to ”ANTSPACE HK3 Water Cooling Container & Dry-Wet Tower Product Manual”, Chapter 9, Article 3, Point 6, “Maintenance of Coolant”!
