E9
Specifications
|
Product Glance |
Value |
||||
| Version |
E9 |
||||
| Model No. |
240-E |
||||
| Crypto Algorithm/Coins |
Ethash/ETC |
||||
| Hashrate, TH/s |
2400 ± 10% |
2280 ± 10% |
2220 ± 10% |
2160 ± 10% |
2100 ± 10% |
| power on wall@25℃, Watt |
1920 ± 10% |
1920 ± 10% |
1920 ± 10% |
1920 ± 10% |
1920 ± 10% |
| power efficiency on wall @25°C, J/TH |
0.8 ± 10% |
0.84 ± 10% |
0.86 ± 10% |
0.89 ± 10% |
0.91 ± 10% |
| Memory |
6 |
||||
|
Detailed Characteristics |
Value |
|
Power Supply |
|
| Power supply AC input voltage, Volt (1-1) |
200~240 |
| Power supply AC Input Frequency Range, Hz |
47~63 |
| Power supply AC Input current, Amp(1-2) |
20(1-3) |
|
Hardware Configuration |
|
| Network connection mode |
RJ45 Ethernet 10/100M |
| Server Size (Length*Width*Height, w/o package), mm(2-1) |
400*195.5*290 |
| Server Size (Length*Width*Height, with package), mm |
680*316*430 |
| Net weight, kg(2-2) |
17.7 |
| Gross weight, kg |
19.4 |
|
Environment Requirements |
|
| Operation temperature, °C |
0~40 |
| Storage temperature, °C |
-20~70 |
| Operation humidity(non-condensing), RH |
10~90% |
| Operation altitude, m(3-1) |
≤2000 |
Notes:
(1-1) Caution: Wrong input voltage may probably cause server damaged.
(1-2) Max condition: temperature 40°C, altitude 0m.
(1-3) Two AC input wires, 10A per wire.
(2-1) Including PSU size.
(2-2) Including PSU weight.
(3-1) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
