Product Parameters
|
Model
|
L3+
|
|
Algorithm | Cryptocurrency
|
Scrypt | LTC/DOGE
|
|
Hashrate, MH/s
|
504M±5%
|
|
Power on wall @25°C, Watt
|
800 ± 10%
|
|
Power efficiency on wall @25°C, J/MH
|
1.6J/MH±10%
|
|
Frequency
|
384M
|
|
Fan(s)
|
2 Fans @ 12 V and 2.4 A
|
|
Fan speed
|
Front: 4200 rpm,rear:3600rpm
|
|
Operation temperature,°C
|
0 – 40°C
|
|
Surrounding humidity
|
5%~95%(non-condensing)
|
|
Noise
|
60dB
|
|
No. of PCIE connectors
|
9
|
|
No. of hash boards
|
4
|
|
No. of chips
|
288 in total
|
|
Chip temperature
|
90℃
|
|
Voltage
|
11.6 ~ 13.0V
|
|
Networking connection mode
|
RJ45 Ethernet 10/100M
|
|
Miner Size (Length*Width*Height, w/o package),mm
|
352 * 130 *187mm
|
|
Miner Size (Length*Width*Height, with package),mm
|
465 * 215 * 305mm
|
|
Net weight, kg
|
4.4 KG
|
|
Gross weight, kg
|
6.5 KG
|
NOTEO:
1.Launched in June 2017, Antminer L3+ is a custom-made device, and it uses the same hardware components. The Antminer L3+ is an upgraded model of the L3, and in terms of performance and competition, the Antminer L3+ is better.
2.The Antminer L3+ has a maximum hash rate of 504Mh/s. It’s almost twice the speed of its previous model, Antminer L3, which was 255M/s.
3.Antminer L3+ consumes around 800W of power, which is two times the power consumption of its predecessor.
