| Specifications
| Product Glance |
Value |
| Model |
L9 |
| Version |
LT1-10 |
| Crypto algorithm | coins . |
Scrypt |LTC+DOGE |
| Typical Hashrate, GH/s(1-1) |
16 |
| Power on wall @25°CWatt(1-1). |
3360 |
| Power efficiency on wall@25°C, J/GH(1-1) |
210 |
| Detailed Characteristics |
Value |
| Single-Phase AC Power supply |
|
| Input voltage, Volt(2-1) |
220~277V |
| Input Frequency Range, Hz |
50~60 |
| Input max current, Amp |
20 |
| Hardware Configuration |
|
| Network connection mode |
RJ45 Ethernet 10/100M |
| Server size (Length*Width*Height, w/o package), mm |
400*195*290 |
| Server size (Length*Width*Height, with package), mm |
570*316*430 |
| Net weight, kg |
14.1 |
| Gross weight, kg |
15.9 |
| Noise@25℃, dBA @25℃ (2-2) |
75 |
| Environment Requirements |
|
| Operation temperature, °C |
75 |
| Storage temperature, °C |
-40~70 |
| Operation humidity(non-condensing), RH |
10~90% |
| Operation altitude, m(2-3) |
≤2000 |
NOTE:
(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values. The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(2-1) Caution: Wrong input voltage may cause server damaged.
(2-2) Max condition: Fan is under max RPM (rotation per minute).
(2-3) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
