S21 lmm

Short Description:


Product Detail

Product Tags

| Specifications


Product Glance Value
Model S21 lmm
Version K1-10
Crypto algorithm/coins SHA256 | BTC/BCH/BSV
Typical Hashrate, TH/s(1-1) 239
Power on wall @25°C, Watt(1-1) 3284
Power efficiency on wall @25°C, J/TH(1-1) 16.0



Detailed Characteristics Value
Power Supply
Power supply AC Input voltage range, V(2-1) 380~415V AC
Power supply AC Input Frequency Range, Hz 50~60
Power supply AC Input current, A(2-2) 12
Adapted AC output power requirement, W(2-3) 6000
Hardware Configuration
Networking connection mode RJ45 Ethernet 10/100M
Server Size (Length*Width*Height, w/o package),mm 364(2-4)*236*293
Server Size (Length*Width*Height, with package),mm 570*316*430
Net weight, kg 16.8
Gross  weight, kg 18.5
Noise, dBA @25 58
Environment Requirements
Operation temperature,°C 0~45
Storage temperature,°C -20~70
Operation altitude,m (2-5) 2000

Notes:

(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical valueThe actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-2) Ambient temperature of 25 equals to inlet oil temperature of 30
(2-1) Caution: Wrong input voltage may cause server damage.
(2-2) Three-phase AC input, 10 A per wire.
(2-3) Caution: It is strongly recommended that the power on wall of the miner does not exceed this value.
(2-4) The height consists a height of 44mm for the  handle.
(2-5) When the miner is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1 for every increase of 300m.

| Working Mode


Working mode NEM(3-1) NEM(3-2)
Operation temperature, °C 0~35 0~35 35~45
Hashrate, TH/s 239 301 278
Power on wall, Watt 3824 5569 5143
Power efficiency on wall, J/TH 16.0 18.5 18.5

Notes:

(3-1) NEM: Normal Energy Mode

(3-2) HEM: High Energy Mode



| Perfermance Curve


  1. Hashrate vs. Ambient Temperature

微信截图_20240725163127

2.J/T vs. Ambient Temperature

微信截图_20240725163159
