| Specifications
| Product Glance |
Value |
| Model |
S21 XP |
| Sub |
270T |
| Version |
10 |
| Crypto algorithm/coins |
SHA256 | BTC/BCH/BSV |
| Typical hashrate,TH/s(1-1) |
270 |
| Power on wall @25℃(1-2), Watt(1-1) |
3645 |
| Power efficiency on wall@25℃(1-2),J/TH(1-1) |
13.5 |
| Detailed Characteristics |
Value |
| Power supply |
|
| Phase |
1 |
| Input voltage range(2-1) , Volt |
220~277 |
| Input frequency range, Hz |
50~60 |
| Maximum input current, Amp |
20 |
| Hardware Ronfiguration |
|
| Network connection mode |
RJ45 Ethernet 10/100M |
| Server size (length*width*height, w/o package), mm |
449*219*293 |
| Server size (length*width*height, with package), mm |
640*360*450 |
| Net weight, kg |
18.7 |
| Gross weight, kg |
21.5 |
| Noise(2-2)@30℃, dBA |
76 |
| Environment Requirements |
|
| Operation temperature,℃ |
-20~45 |
| Storage temperature,℃ |
-20~70 |
| Operation humidity(no condensation), RH |
10%~90% |
| Operation altitude(2-3), m |
≤2000 |
Notes:
(1-1) The Hashrate value, Power on wall, and Power efficiency on wall are all typical values, The actual Hashrate value fluctuates by ±3%, and the actual Power on wall and Power efficiency on wall fluctuate by ±5%.
(1-2) Inlet air temperature.
(2-1) Caution: Wrong input voltage may probably cause server damaged.
(2-2) The noise is loudest when the fan is under maximum RPM(rotation per minute).
(2-3) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
| Performance Curve
- Hashrate vs. Ambient Temperature
- J/T vs. Ambient Temperature
