Product Description
Specifications:
|
Product Glance
|
| Model |
Z11
|
| Algorithm | Cryptocurrency |
EquiHash | ZEC
|
| Hashrate（KSol/s） |
135
|
| Power on wall（Watt) |
1418 ±10%
|
| Power efficiency on wall @25°C (J/Ksol) |
10.5J/K ±10%
|
|
Hardware Configuration
|
| Networking connection mode |
RJ45 Ethernet 10/100M
|
| Miner Size (Length*Width*Height, w/o package),mm(1-1) |
228*134*279
|
| Miner Size (Length*Width*Height, with package),mm |
391*243*353
|
| Net weight, kg(2-1) |
5.08
|
| Gross weight, kg |
5.8
|
| Chip boards |
3
|
| Chip size |
12nm
|
| Chip count |
54
|
| Noise level |
70 dB
|
| Fan(s) |
2
|
| Fan speed |
6000 rpm
|
| Voltage |
11.6~13.0V
|
| Environment Requirements |
Min
|
Typ
|
Max
|
| Working temperature（°C） |
0
|
25
|
40
|
| Storage temperature（°C） |
-40
|
25
|
85
|
| Operation humidity(non-condensing), RH |
5%
|
|
95%
|
NOTE:
(1-1) NOT Including PSU size
(2-1) NOT Including PSU weight
